Material: Body: Carbon Steel , Pin: Alloy Steel
Finishing: Hot Dip Galvanized
Heat treated: Tempered and Quenched
Minimun Utimate Strength: 6 Times The Working Load Limit.
Packing: Gunny Bag

ITEM NO.	Nominal Size (in.)	Working Load Limit(t)*	Weight Each(lbs.)	Dimensions (in.)									Tolerance+/-
				A	B	D	F	G	K	M	P	R	G	A
100081	1/4	1/2	.13	.47	.31	.25	.62	.91	1.59	.97	1.56	.25	.06	.06
100082	5/16	3/4	.23	.53	.38	.31	.75	1.07	1.91	1.15	1.82	.31	.06	.06
100083	3/8	1	.33	.66	.44	.38	.92	1.28	2.31	1.42	2.17	.38	.13	.06
100084	7/16	1-1/2	.49	.75	.50	.44	1.06	1.48	2.67	1.63	2.51	.44	.13	.06
100085	1/2	2	.75	.81	.64	.50	1.18	1.66	3.03	1.81	2.80	.50	.13	.06
100086	5/8	3-1/4	1.47	1.06	.77	.63	1.50	2.04	3.76	2.32	3.56	.63	.13	.06
100087	3/4	4-3/4	2.52	1.25	.89	.75	1.81	2.40	4.53	2.75	4.15	.81	.25	.06
100088	7/8	6-1/2	3.85	1.44	1.02	.88	2.10	2.86	5.33	3.20	4.82	.97	.25	.06
100089	1	8-1/2	5.55	1.69	1.15	1.00	2.38	3.24	5.94	3.69	5.39	1.00	.25	.06
100090	1-1/8	9-1/2	7.60	1.81	1.25	1.13	2.68	3.61	6.78	4.07	5.90	1.25	.25	.06
100091	1-1/4	12	10.81	2.03	1.40	1.25	3.00	3.97	7.50	4.53	6.69	1.38	.25	.06
100092	1-3/8	13-1/2	13.75	2.25	1.53	1.38	3.31	4.43	8.28	5.01	7.21	1.50	.25	.13
100093	1-1/2	17	18.50	2.38	1.66	1.50	3.62	4.87	9.05	5.38	7.73	1.62	.25	.13
100094	1-3/4	25	31.40	2.88	2.04	1.75	4.19	5.82	10.97	6.38	9.33	2.12	.25	.13
100095	2	35	46.75	3.25	2.30	2.10	5.00	6.82	12.74	7.25	10.41	2.36	.25	.13
100096	2-1/2	55	85.00	4.12	2.80	2.63	5.68	8.07	14.85	9.38	13.58	2.63	.25	.25
100097	3	85	124.25	5.00	3.25	3.00	6.50	8.56	16.87	11.00	15.13	3.50	.25	.25
